Alloy Steel
Alloy Steel Fasteners are made in different alloy types. They have different composition with chromium, vanadium, tungsten and molybdenum inclusive. The addition of these elements in the composition gives the alloys the strength and corrosion resistance. Big Bolt Nut is one of the leading Alloy Steel Fasteners manufacturers In India and a leading supplier.
The alloy steel fasteners come in different dimensions, grades and types. There are fasteners ranging from M12 to M72 in required length and the types differ such as studs, bolts, nuts washers and so on. The Grade B7 Alloy Steel Bolts are manufactured in a chromium molybdenum alloy and are heat treated by quenched and tempered methods. This production method improves the strength of the ASTM A193 Grade B7 Nuts.
Alloy steel grades used in our factory are 40 Cr, 42Cr MoV4, EN 18, EN 19, EN 24, EN 31, we also use alloy steel grades in petrochemical and oil and gas industry.
|
Standard / Material grade |
C |
MN |
P |
S |
Si |
CR |
MO |
AI |
V |
|
ASTM A193 B7 (Cr- Mo AISI 4140,4142,4145 ) |
0.37-0.49 |
0.65-1.10 |
0.035 Max |
0.04 Max |
0.15-0.35 |
30.75-1.20 |
0.15-0.25 |
- |
- |
|
ASTM A193 B7M (Cr- Mo AISI 4140,4142,4145 ) |
0.37-0.49 |
0.65-1.10 |
0.035 Max |
0.04 Max |
0.15-0.35 |
30.75-1.20 |
0.15-0.25 |
- |
- |
|
ASTM A193 B16 (Cr- Mo -V ) |
0.36-0.47 |
0.45-0.70 |
0.035 Max |
0.04 Max |
0.15-0.35 |
0.80-1.15 |
0.50-0.65 |
0.015Max |
0.25-0.35 |
|
ASTM A193 B5 (5% Cr AISI 501) |
0.10 max |
1.00 max |
0.040 max |
0.030 Max |
1.00 Max |
0.40 -6.00 |
0.40 -0.65 |
- |
- |
|
ASTM A320-L7 (Cr- Mo AISI 4140,4142,4145 ) |
0.38-0.48 |
0.75-1.00 |
0.035 Max |
0.04 Max |
0.15-0.35 |
0.80-1.10 |
0.15-0.25 |
- |
- |
|
ASTM A 320 L7M |
0.38-0.48 |
0.75-1.00 |
0.035 Max |
0.04 Max |
0.15-0.35 |
0.80-1.10 |
0.15-0.25 |
- |
- |
|
ASTM A194 Gr.2H |
0.40 Min |
1.00 Max |
0.040 Max |
0.050 Max |
0.40 Max |
- |
- |
- |
- |
|
ASTM A194 Gr.2HM |
0.40 Min |
1.00 Max |
0.040 Max |
0.050 Max |
0.40 Max |
- |
- |
- |
- |
|
ASTM A194 Gr.4 |
0.40-0.50 |
0.70-0.90 |
0.035 Max |
0.04 Max |
0.15 - 0.35 |
0.20 - 0.30 |
0.15-0.25 |
- |
- |
Over the past few years we have manufactured many different kind of stainless steel grades of bolts and nuts, however the above grades mentioned in the table are the main grades which we are manufacturing consistently. With constant improvement in quality we have been able to excel in the manufacturing process for the above steels and their respective grades.
The applications of these fasteners include power plants, petrochemical industries, oil drilling applications, oil and gas pipe lines and many others. The ASTM Ba94 Alloy Steel Screws are used to fit components together with just screws without the need for nuts or welding procedures. The high heat applications such as exhaust components, heat exchangers and condensers also used these fasteners. The studs or Grade B6 Threaded Rod types are also used to combine two components together by having threads at both ends of the rods. Please contact us for more information and pricing of the products such as the ASTM A194 Grade B7 Nut Bolt and others of your choice.
Big Bolt Nut manufactures and exports the entire range of Petrochemical stud bolts, alloy steel bolts, alloy steel bolting, alloy steel stud bolts, stud bolts oil and gas, B-7 stud bolts the popular grades of Alloys steel are from ASTM A 193 / SA 194 and A 194 / SA 194 grades like B7, B7M, L7 and L7M grades.
